- 3FParts Product Code (3PC)
- 3F-00125-006-1108
- Head Diameter (D)
- 7mm, Tolerance: +0/-0.22mm
- Head Length (H)
- 4mm, Tolerance: +0/-0.18mm
- Hexagon Depth (P)
- 2mm
- Socket Size (J)
- 3mm
- Material
- Stainless Steel 304 (A2-70)
- Thread Size (Dia.)
- M4
- Length (L)
- 100mm
- Manufacturing Standard
- DIN 912
- Fully Threaded
- Yes
- Thread Pitch
- 0.70 mm
M4 x 100mm Socket Head (Allen Bolt) Cap Screw (DIN 912) - Stainless Steel 304 (A2-70)
- 7mm, Tolerance: +0/-0.22mm Head Diameter (D)
- 4mm, Tolerance: +0/-0.18mm Head Length (H)
- 2mm Hexagon Depth (P)
- 3mm Socket Size (J)
- Stainless Steel 304 (A2-70) Material
- M4 Thread Size (Dia.)
- 100mm Length (L)
- DIN 912 Manufacturing Standard
- Yes Fully Threaded
- 0.70 mm Thread Pitch
